2 Post Hoist – 4 Ton - Baseplate Model
Feature
- Dimensions suit home garage/ shed use
- Single phase 240v motor as standard
- Sub-frame provides additional safety
- 4 Ton raƟng will lift 4WD vehicles with ease
- Minimum 3 metre ceiling height required
- 4000kg/ 4 ton safe load limit
- Lifting height of 1.9m (plus screw pad adjustment and raising adapters)
- Dual hydraulic cylinders with chain driven carriages
- Adjustable screw pads and 4 additional raising adapters are included
- Strong single piece column design
- Durable powder coated finish
- Rubber door protectors
- Symmetric two and three stage arms
- Low profile 50mm high base plate
This base plate model 2 Post Hoist is built tough to suit a wide range of vehicles — It’s a great
solution for home mechanics and workshops that are limited by lower ceiling heights.
Safety Features
Manual safety locking system with safety latches in each column
Dual point release system
Heavy duty 6mm thick columns & carriages
10mm steel wire rope equalising cables
Anti-surge valve in the hydraulic power unit
Sub-frame design provides additional safety
What’s Included?
2 post hoist with all bolts, cables, lines and fixings
240V single phase hydraulic power unit
Concrete anchor bolts
Detailed installation instructions
What’s Not Included?
Hydraulic oil
Setup of power units electrical connection
Shed Requirements
150mm deep concrete at 32mpa
Minimum ceiling height of 3m
Warranty & Certifications
3 year Australian warranty* includes structure, hydraulics & electrics
Australian WorkSafe registered design
CE certification
